    SM Duplex SC/UPC-SC/UPC 2.0mm Fiber Optic Patch Cord PVC LSZH

    Ask Lasest Price
    Brand Name : KCO
    Model Number : SC-SC-UPC-SM--DX 2.0mm-1.0m
    Certification : ISO9001, RoHS
    Price : Negotiation
    Payment Terms : Western Union, T/T, L/C
    Delivery Time : 2~5 days after get payment
    • Product Details
    • Company Profile

    SM Duplex SC/UPC-SC/UPC 2.0mm Fiber Optic Patch Cord PVC LSZH

    Fiber Optic Patch Cord SM Duplex SC/UPC-SC/UPC 2.0mm PVC LSZH 1.0m


    Kocent Optec Limited provides OEM service for all kinds of fiber optic patch cables, including common type of FC, LC, SC, ST, and MT-RJ, E2000, MPO, MTP, ESCON, FDDI, DPLC, LC Uniboot, SC Uniboot. Specially in LC uniboot patch cable.


    We also provides a high optical performance Duplex SC/UPC-SC/UPC optical fiber patch cords which save half of the operation spaces required.


    SC/UPC-SC/UPC Duplex patch cords are now used as the preferred option of fiber patch cords for data center high density connectivity.


    Fiber Optical Patch Cord Summary:

    About Fiber optic connector , the ITU call it as a kind of passive light component which can connect two or more fiber lines stably but not always. It can make a close connection for fiber cable and make a wonderful transmission for the light energy .


    Key Features:

    1 Low IL & high RL

    2 Good exchangeability & durability

    3 High reliability and stability

    4 UL-rated plastic housing

    5 Patch cords accord with GR-326,ISO9001,ROHS


    Application :

    1 fiber optic communication network

    2 fiber broadband access network

    3 CATV

    4 Active device termination

    5 Metro and Local Area Networks

    6 Telecommunication networks


    Ordering options:

    1 Connector type: FC, SC, LC, ST

    2 Ferrule End-face: PC, UPC, APC

    3 Core Type: Single Mode 9/125

    4 Fiber Core: Duplex

    5 Cable Diameter: φ2.0mm, φ0.9mm

    6 Cable Length: 1, 2, 3 meter or customized

    7 Cable type: PVC, LSZH


    Specification:

    ModeSMMM
    PolishUPCAPCPC
    Insertion Loss

    Typical ≤0.2dB

    Maximum ≤0.3dB

    ≤0.25dB
    Return Loss≥50dB≥65dB≥35dB
    Interchangeability≤0.2dB
    Repeatability≤0.1dB
    Durability≤0.2dB (1000 times mating)
    Tensile Strengh> 10kg
    Temperature≤0.2dB (-40+85 sustain 100 hours)
    Humidity

    ≤0.2dB (+25+65 93 R.H.100 hours)




    OEM/ODM Service:

    If you want to show your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.


    Packing:

    According to Stardard Export Packing.

    Carton box, wooden box, wooden pallet.


    Shipping:

    - International express such as UPS, TNT, DHL, etc

    - Internatioal air: CA, AA, EA, etc

    - By sea
