    SM LC Duplex 10G 10km 1310nm SFP-10G-LR Fiber Optic Transceiver For Cisco Switch

    Ask Lasest Price
    Brand Name : KCO, Kocent Optec Limited
    Model Number : SFP-10G-LR
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 20,000 pcs/ month
    Delivery Time : 7~14 days after get payment
    • Product Details
    • Company Profile

    SM LC Duplex 10G 10km 1310nm SFP-10G-LR Fiber Optic Transceiver For Cisco Switch

    SM LC Duplex 10G 10km 1310nm SFP-10G-LR Fiber Optic Transceiver SFP+ For Cisco Switch

    Descriptions:

    - Small Form-factor Pluggable (SFP) is a compact, hot-pluggable network interface module format used for both telecommunication and data communications applications.

    - SFP modules facilitate high-speed communication between switches and network components such as routers and other devices.
    - It is mainly used with copper or fiber optic cables.
    - Its small form factor makes it ideal for areas that may not be very accessible.
    - SFP-10G-LR 10GBASE-LR 1310nm 10km SFP+ Optical Fiber Transceiver is a high performance and cost-effective SFP+ transceiver module supporting data-rate of 10.3125Gbps (10GBASE-LR) or 9.953Gbps (10GBASE-LW) over single mode optical fiber.
    - This transceiver is programmed to be compatible with a wide range of Cisco network equipment such as 10 Gigabit Ethernet (10 GbE) Switches, Routers, Network Interface Cards (NICs) and Media Converters, which makes it be an ideal equivalent to high-cost Cisco SFP-10G-LR optics module.
    - This transceiver is manufactured with high-quality components and tested strictly to meet or exceed original manufacturer specifications and optimized for data center networks applications. The SFP+ transceiver module fully complies with SFP+ Multi-Source Agreement (MSA) standards SFF-8431, SFF-8432 and IEEE 802.3ae 10GBASE-LR/LW.
    - This SFP+ transceiver module also provides a unique enhanced digital diagnostic monitoring interface(DDMI) per SFF-8472, which providing real-time monitoring of the transceiver optics temperature, laser bias current, optical power, received optical power and transceiver optics supply voltage.
    - The transceiver is hot-swappable input/output device which allows a 10 Gigabit Ethernet port to link with a fiber optic network.
    - OEM specific configuration data is loaded on to the EEPROM of the transceiver at the factory, allowing this transceiver to initialize and perform identically to an OEM transceiver.
    - This transceiver may be mixed and deployed with other OEM or third party transceivers and will deliver seamless network performance.


    Feature:

    - Hot-pluggable SFP+ footprint
    - Electrical interface compliant to SFF-8431
    - Compliant with SFF-8472
    - 10Gb/s serial optical interface compliant to 802.3ae 10GBASE-LR
    - 1310nm DFB transmitter, PIN photo-detector
    - Distance up to 10km on single mode fiber
    - LC Duplex connector
    - Built-in digital diagnostic functions
    - Single 3.3V power supply


    Application

    - High speed data center
    - Metro
    - FTTx
    - High speed ethernet system
    - 10GBASE-LR/10GBASE-LW Ethernet
    - 10G Fiber Channel
    - 10GbE Data Center Switches and Routers
    - 10GBASE-SR at 10.3125Gbps
    - 10GBASE-SW at 9.953Gbps
    - Other active optical links


    Specification:

    Compatible OEM Part NumberSFP-10G-LR
    Form FactorSFP+Data Rate10Gb/s
    Wavelength1310 nmFiber TypeSMF
    Max Distance10 kmOptical ComponentsDFB + PIN
    Transmitter Power-6 ~ 0dBmExtinction ratio> 3.5 dB
    Receiver Sensitivity< -14.4 dBmReceiver Overload> 0.5 dBm
    TX Power-6.5~-0.5dBmReceiver Sensitivity< -14.4dBm
    ConnectorLC DuplexDigital Diagnostic MonitoringYes
    Environment TemperatureOperating: 0°C to 70°C
    Storage: -40°C to 85°C
    Weight0.03 kg

    Products photos:


    Compatible switch:
    Fiber Optic SFP Tranceiver Module Catalog:
    SFP TypeStandardData RateWavelengthFiber TypeMax DistanceTypical ConnectorDOM
    SFPSFP MSA

    155Mbps

    622Mbps

    1.25Gbps

    2.125Gbps

    2.5Gbps

    3Gbps

    4.25Gbps

    850nm

    1310nm

    1550nm

    CWDM

    DWDM

    BIDI

    OM1

    OM2

    OS1

    OS2

    200km

    LC

    SC

    RJ-45

    NO or YES
    SFP+

    IEE802.3ae

    SFF-8431

    SFF-8432

    6Gbps

    8.5Gbps

    10Gbps

    850nm

    1310nm

    1550nm

    CWDMD

    WDM

    BIDI

    Tunable

    Copper

    OM3

    OM4

    OS1

    OS2

    100km

    LC

    RJ-45

    YES
    QSFP+

    IEEE 802.3ba

    QSFP+ MSA

    SFF-8436

    SFF-8636

    Infiniband 40G QDR

    41.2Gbps

    850nm

    1310nm

    832-918nm

    OM3

    OM4

    OS1

    OS2

    80km

    LC

    MTP/MPO

    NO or YES
    SFP28

    IEEE 802.3by

    SFP28 MSA

    SFF-8472

    SFF-8432

    25.78Gbps

    850nm

    1310nm

    BIDI

    OM3

    OM4

    OS1

    OS2

    40kmLCYES
    QSFP28

    IEEE 802.3bm

    QSFP28 MSA

    SFF-8665

    SFF-8636

    103Gbps

    112Gbps

    850nm

    1310nm

    CWDM4

    OM3

    OM4

    OS1

    OS2

    80km

    LC

    MTP/MPO-12

    YES

    OEM/ODM Service:
    If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.


    Packing:
    According to Stardard Export Packing.
    Carton box, wooden box, wooden pallet.


    Shipping:
    - International express such as UPS, TNT, DHL, etc
    - Internatioal air: CA, AA, EA, etc
    - By sea: COSCO, HUYNDAI, etc

    - Standard shipping port: Shenzhen, Hongkong, Ningbo
