    IP65 Outdoor Fiber Optic Cable Termination Box ODP FDB ODF NAP CTO KCO-FDB-0424D

    Ask Lasest Price
    Brand Name : KCO, Kocent Optec Limited
    Model Number : KCO-FAT-24W
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 20,000 pcs/ month
    Delivery Time : 7~14 days after get payment
    • Product Details
    • Company Profile

    IP65 Outdoor Fiber Optic Cable Termination Box ODP FDB ODF NAP CTO KCO-FDB-0424D


    KCO-FDB-0424D Outdoor Fiber Optic Distribution Termination Box ODP FDB ODF NAP CTO Box


    Descriptions:
    - KCO-FDB-0424D fiber optic distribution box is able to hold up to 24 subscribers.It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system.

    - KCO-FDB-0424D fiber optic distribution box is used for outdoor application, it can be wallmount or pole mount.

    - Its waterproof class can meet IP65.

    - KCO-FDB-0424D series outdoor wall mount and pole mounted fiber optic termination box for FTTH drop cable entry or exist, it is available in 3 colors:

    Black: KCO-FDB-0424DB

    White: KCO-FDB-0424DW

    Grey: KCO-FDB-0424DG

    - KCO-FDB-0424D is able to hold up to 24 subscribers.

    - It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system.

    - It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.


    Feature:

    - 1*16 splitter can be installed as an option

    - Efficient cable management

    - 24 ports for drop cable outports

    - Waterproof design with IP-65 protection level.

    - Integrated with splice cassette and cable management rods

    - Manage fibers in a reasonable fiber radius cnodition

    - Easy to maintain and extend the capacity

    - Fiber bend radius control more than 40mm

    - Suitable for the fusion splice or mechanical splice


    Quick Information:

    MaterialSizeMax CapacityInstallation sizeWeightColor
    PC+ABS320*240*100mmSC 24ports

    Box PLC

    1X16(SC)

    Tube PLC

    1X8(SC)

    206*274mm1.5kgLight Grey

    Function:

    - P/N: KCO-FDB-0424D

    - Material:

    ABS

    ABS+PC

    - Long life time: about 20 years

    - Can accommodate 1x4, 1x6, 1x8, 1x12, 1x16, 1x24 PLC splitter.

    - Rainfall resistant, IP65 outdoor using.

    - Can load 24pcs LC, FC, ST, SC, E2000 … adapters.

    - Installation:

    Wall mounting

    Pole mounting

    - The cover with 2 reinforcing closing pieces, easy to open and close.

    - 02pcs cable entry ports (max. diameter 8mm cable) for cable entry without cutting;

    - 24pcs exit ports for FTTH drop cable.


    Products photos:




    Specifications:

    ModelKCO-FDB-0424D
    MaterialPC+ABS or ABS
    Dimension320*240*100mm
    Cable Entry2 cable entrance: 10-16.5mm
    Drop cable port24 ports
    Applicable cable diameter2*3mm FTTH drop cable, 2*5mm figure 24 FTTH drop cable
    Max. Capacity24 Fibers, 1 tray x 12F
    AdapterMax. 24pcs SC simplex (LC, FC, E2000,... optional)
    Sealing structureMechanical sealing with PE waterproof sealing ring
    PLC SplitterMax. micro plug-in 1x24 Splitter
    ColorGray, White or Black
    IP GradeIP65
    Operating Temperature-40°C~+80°C
    Relative Humidity<95%(+40°C)
    Insulated Resistance>2x10MΩ/500V(DC)
    Installation Method
    (in overstriking)
    Floor Standing / Wall Mounted / Pole Mounted /
    Corridor Mounted / Mounted in Cabinet

    Related Products:

    OEM/ODM Service:
    If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.



    Packing:
    According to Stardard Export Packing.
    Carton box, wooden box, wooden pallet.


    Shipping:
    - International express such as UPS, TNT, DHL, etc
    - Internatioal air: CA, AA, EA, etc
    - By sea: COSCO, HUYNDAI, etc

    - Standard shipping port: Shenzhen, Hongkong, Ningbo
